Description:
KP-HDR50 is a rack-mounted high-definition H.265 / H.264 COFDM wireless video receiver, standard 1.5U rack designed. The wireless receiver support high quality broadcast standard 1920*1080P/i video output with both HDMI, and BNC interfaces. KP-HDR50 microwave receiver can be configured easily and manually, like frequency, rf bandwidth, encryption, at the LCD configred panel on receiver body.
KP-HDR50 wireless digital video receiver has the strong anti-jamming capacity, which overcomes the reflection and cover caused by transmission multipath simulation technique and conventional modulation techniques, to realize high-speed photography and real-time receiving with high quality image in NLOS(Non-Line-of Sight) or complicated working environment.
It's with HDMI and CVBS vido output and can be customized with RJ45 Ethernet port, support remote image monitoring. With flexible tailor made solution, the KP-HDR50 digital receiver is suitable for any cofdm video transmitter of our company.
Feature:
1) COFDM HD/SDI 1080P receiver; Matched with HD/SDI 1080P transmitter
2) Supported multi-socket output;
3) Rack design,easy to installed in Car;
4) Transmit video and audio signal simultaneously;
5) Can customized with RS485/RS232 data control together;
6) Support NLOS video transmission receiving;
7) Work well under fast moving signal receiving and support NLOS trasnsmission
8) Latest technology: COFDM modulation
Specifications:
| Voltage | AC220V±20V, DC14V~DC16V |
| Current | ≤1.A / DC12.5V |
| Receiving sensitivity | ≤-102dBm /4MHz, |
| ≤-95dBm /8MHz |
| BER | BER≤1×10-4 |
| Frequency input range | 300MHz~4400MHz (Optional) |
| Output interface | N(type),Dual antenna diversity reception technology |
| RF bandwidth | 2/2.5/4/8MHz(adjustable) |
| Modulation | COFDM |
| Constellation | QPSK,16QAM,64QAM |
| FEC | 1/2, 2/3, 3/4, 5/6, 7/8 |
| Carrier | 2K |
| Guard Interval | 1/4, 1/8, 1/16, 1/32 |
| Video formats and amplitude | PAL/NTSC, 1Vp-p/75Ω |
| Video compression | H.264/MPEG-2 |
| Video output interface | HDM-I; CVBS |
| Video channel characteristic | Differential gain DG≤1.5% Differential phase DP≤1° |
| System distortion degree |
| Decryption mode | AES |
| Audio output | Left and right channel and stereo |
| Dimension | 480*220*44mm |
| Weight | 3.5kg |
| Type | mobile cofdm hd video transmitter and receiver long range |
